2WHM20-40 130

Enerji Tasarruflu Sirkülasyon Pompaları

2WHM20-40 130

ÖZELLİKLER Kapalı devre sistemler için uygun dökme demir gövde, kullanma suyu ve açık devre sistemler için paslanmaz çelik gövde; yoğuşmalı ortamlarda çalışmaya uygun, chiller suyu sirkülasyonu için tasarlanmış kapsüllü BMC motor. PWM versiyonu – sistem kontrol cihazından gelen PWM kontrol sinyali ile harici olarak kontrol edilir; PWM A profiline sahiptir ve hem güç geri bildirimi hem de debi geri bildirimi sunar. AUTO versiyonu – entegre pompa kontrolörü tarafından dahili olarak kontrol edilir.
Product name: 2WHM20-40 130

Technical

Maximum flow 2.5m3/h
Maximum head 4m
TF class 110
Approvals VDE,CE

Materials

Pump housing Cast iron/Stainless steel
Impeller PES + GF30%

Installation

Maximum ambient temperature 40°C
Maximum operating pressure 10 bar
Type of connection G
Size of connection 1 inch
Pressure rating for connection PN10
Port to port length 130

Liquid

Pumped liquid Water
Liquid temperature range 2 ~ 110°C
Selected liquid temperature 60°C
Density 983.2 kg/m3

Electrical data

Minimum power input – P1 5 W
Power input – P1 30 W
Mains frequency 50 / 60 Hz
Rated voltage 1 x 230V
Maximum current consumption 0.28 A
Enclosure class 44
Insulation class F
Built-in motor protection NONE
Thermal protection ELEC

Controls

Internal control AUTO
External control PWM

Others

Energy (EEI) 0.20
Terminal box position 12H
Net weight 1.81kg
Gross weight 2.218kg
Shipping volume 475*310*195mm
